Shade Controller
C-400-12-DS00
The Shade Controller is the ideal Bluetooth® Mesh Control for drapes or blinds. Receiving its power from the shades motor, no external power supply is needed.
Drapes or blinds can be controlled by the BubblyNet App and the Q Series Keypad, as separate engraved keypads specifically for shade control or included as part of a scene with or without light control. Occupancy Sensors and Schedulers can also work seamlessly with the controller for added flexibility.
Oops, that's an error. Try refreshing
For more information please open this page in the HubSpot page editor.Login or contact sales to view pricing.
Technical Description
The RS485 Controller is the ideal solution for standalone projects as well as the backbone of complex mesh networks.
- Power Input: 5VDC to 30VDC
- RS485: Forest Drapery Protocol Compatible
- Operating Temperature: 50° to 104°F (10° to 40°C)
- Indoor Use Only
- Dimensions: 3.5” x 1.7” x 1.36" (90 x 43.2 x 34.5mm)
The installation of the RS485 Controller is very simple. Plug and play, just connect the Cat 6 cable from the shade motor into the BubblyNet Controller. Once powered up, the device broadcasts its identification code waiting to be commissioned through the BubblyNet App.
The integration, interface and testing for any special application will be quoted as a non-recurring charge.
For best results, drivers need to be installed within 30 feet of the closest device within the Bluetooth® Mesh network. Signal strength significantly decreases in presence of metal barriers such as when devices are enclosed in metal boxes.
