Occupancy + Daylight Sensor
S-MD-C12
The Occupancy + Daylight Sensor is a recessed or trimless ceiling-mounted device that combines Passive Infrared (PIR) motion sensing with advanced daylight harvesting capabilities. This sensor is designed to automatically control lighting based on both motion detection and ambient light levels, providing energy-efficient illumination in indoor environments.
Oops, that's an error. Try refreshing
For more information please open this page in the HubSpot page editor.Login or contact sales to view pricing.
Technical Description
- Sensor Type: PIR Occupancy Sensor
- Lux Detection Range: 0-1000 Lux
- Detection Angle: 130°
- Input Voltage: 12-24VDC
- Current Consumption: 30mA
- Max Power Consumption: 0.7W
- Mounting Height: 12’ (3.7m) MAX
- Max Detection Area*: 26’ (8m) Diameter
- Operating Temperature: 32°F to 113°F (0°C to 45°C)
- Relative Humidity: 0%-95%
- Mounting: Recessed and Trimless options in Ceiling
- Dimensions: 1.26”
- Warranty: 2 Years
12-24VDC power needs to be supplied to the sensor, either with one AC/DC transformer or with the auxiliary DC output of a BubblyNet Controller, not included. For best results, sensors need to be installed within 30 feet of the closest device within the Bluetooth® Mesh network. Signal strength significantly decreases in presence of metal barriers such as when devices are enclosed in metal boxes.
